SATA
MDS-UK
| Series Name | MDS-UK | ||||
|---|---|---|---|---|---|
| Interface | SATA Revision 3.1 | ||||
| Capacity Coverage | 8GB ~ 256GB | ||||
| Capacity | |||||
| SLC | 8GB ~ 32GB | ||||
| MLC | 32GB ~ 256GB | ||||
| 2D pSLC | 16GB ~ 128GB | ||||
| 3D TLC | 32GB ~ 256GB | ||||
| 3D pSLC | 16GB ~ 64GB | ||||
| Performance Overview | Seq. R : 550 MB/s ; Seq. W : 460 MB/s | ||||
| Performance | |||||
| SLC | Seq. R : 550 MB/s ; Seq. W : 145 MB/s | ||||
| MLC | Seq. R : 550 MB/s ; Seq. W : 460 MB/s | ||||
| 2D pSLC | Seq. R : 550 MB/s ; Seq. W : 450 MB/s | ||||
| 3D TLC | Seq. R : 550 MB/s ; Seq. W : 450 MB/s | ||||
| 3D pSLC | Seq. R : 550 MB/s ; Seq. W : 450 MB/s | ||||
| Standard Operating Temperature | 0~70°C | ||||
| Extended Operating Temperature | -40~85°C | ||||
| Dimension LxWxH (mm) | Type.1 : 43.67mm (L) x 22.00mm (W) x 7.50mm (H) Type.2 : 44.60mm (L) x 26.80mm (W) x 9.00mm (H) with Housing Type.3 : 37.5mm (L) x 22.00mm (W) x 15.00mm (H) |
||||
| Technology | #S.M.A.R.T #conformal coating | ||||
Datasheet: DS_MDS-7xUK_V1.7
